Millennium Cylinder Power Assembly Kit Contents SA10200-A20P For: O-200-A B; C-125-2; C-145-2 2H; O-300-A B C D
| Vendor Part Number | Quantity | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA2106 + | 1 | Insert | 08-10936 | $39.50 | |
| SA641793 + | 1 | Seat | 08-11395 | $30.50 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $11.95 | |
| SA21284 + | 2 | Helicoil | 08-10938 | $15.50 | |
| SA22949 M05 + | 4 | Bushing, Rocker Shaft | 08-10955 | $4.35 | |
| SA401870 + | 2 | Stud | 08-11047 | $8.85 | |
| SA402151 + | 2 | Stud | 05-03634 | $6.50 | |
| MS20913-1 + | 1 | Plug | 08-10816 | $9.50 | |
| SA40762 | 1 | Valve Cover, O-200 | 08-11056 | $34.50 | |
| SA10204 | 1 | Valve | 08-10911 | $166.75 | |
| SA21361 | 4 | Valve Lock | 08-10940 | $1.60 | |
| SA24026 | 1 | Valve Spring Retainer | 08-10959 | $4.35 | |
| SA24029 | 2 | Spring | 08-10960 | $11.50 | |
| SA24031 | 2 | Spring | 08-10962 | $10.50 | |
| SA24044 | 1 | Retainer, Valve Spring | 08-10963 | $4.55 | |
| SA625958 | 2 | Spring | 08-11216 | $8.50 | |
| SA625961 | 2 | Seat, Spring | 08-11217 | $19.70 | |
| SA641792 | 1 | 30 Degree Valve | 08-11394 | $79.65 | |
| SA21153 | 1 | Shaft | 08-10937 | $41.65 | |
07-03572 | |||||
| 22250 | 1 | Gasket | 07-03559 | $2.15 | |
| SA530162 | 1 | Gasket | 08-11130 | $6.90 | |
| SA539840 | 1 | Push Rod Seal | 07-03556 | $8.85 | |
| SA632837 | 2 | Gasket | 632837 | $8.75 | |
| SA530928 | 1 | Gasket | 08-00317 | $3.50 | |
| SA2000 | 1 | Ring | 08-10926 | $34.50 | |
| SA1000 | 2 | Ring | 08-10903 | $12.50 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
Documents
Reviews
I am not sure what brand I had before but they were black gaskets and they failed in 150 hours. These Superior gaskets are red material and seem slightly stiffer. Hopefully they last longer than the other brand.
Verified Purchase
Superior SA22250 Continental Intake Gasket
perfect fit
Verified Purchase
TCM Cylinder Base Seal 21477
SA530928 Gasket
Verified Purchase
Superior Continental Push Rod Gasket SA530928
Excellent quality.
Verified Purchase
Superior Push Rod Seal Cont. 539840
MORE ECONOMY
Verified Purchase
Superior Push Rod Seal Cont. 539840
Perfect fit, just what I needed - arrived in 2 days.
Verified Purchase
Superior SA22250 Continental Intake Gasket
Worked well.
Verified Purchase
Superior SA22250 Continental Intake Gasket
Good fit
Verified Purchase
TCM Cylinder Base Seal 21477
I find that these particular gaskets work great on my Continental 0-300 engine.
Verified Purchase
Superior SA530162 Gasket
These value covers are for the O-300 Continental Engine and they fit perfectly. Very satisfied.
Verified Purchase
Superior SA40762 Cover, Valve
