Gill GC-024 24VDC Charger 110V

3 Reviews 7 Answered Questions
$257.95/Each
Quantity
Add to Wishlist
Part# 11-10570
MFR Model# 60218

Overview

IMPORTANT: These chargers will only function when connected to 110-120V input. Do not connect them to 220-240V or you may damage the charger.

Light weight / High strength aluminum case, Fully automatic: 3 stage charger can be left on the battery for long periods, Charge Status LED's: Power on, charging and full charging.

California Prop 65 Warning Symbol

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Features

  • Light weight / High strength aluminum case
  • Fully automatic: 3 stage charger can be left on the battery for long periods
  • Charge Status LED's: Power on, charging and full charging
  • Circuit protection: reverse polarity and short circuit protected (fused)
  • UL and CE approved
  • Power cord length 6 feet and 4 foot Charger cord with alligator clips
  • Charge control: Modified constant current charge to a constant finishing voltage, then to a float standby
  • Supported with a 2 year warranty

Specifications

  • Input: 110-120 VAC
  • Input Frequency: 50/60 Hz
  • Output: 7 Amps
  • Output EQ: 28.8 VDC +/-0.2 Volts
  • Output Float: 26.3 VDC +/-0.2 Volts
  • Dimensions: 7.5"W x 3.5"H x 1.9"D
  • Weight: 2.1 pounds
  • Frequently Purchased With
  • Customers Also Viewed
  • Related Items

Reviews

Submit a Review

Shoulda got one of these a long time ago. Works great!

William L
April 12, 2020

Getting use to an aircraft I just purchased as well as ATC communications. Mistakenly left something on and ran battery down to a point where starter wouldnt work. Overnight charge with this and I was back in business.

Tony
December 29, 2019

great little 24v charger, just what i needed.

Roland D
February 17, 2018

Q&A

Submit

Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Is this the same as the GSE 076/PN GC-024E that is required for use in the Embraer Phenom 300 aircraft?

No, for the GC-024E, please see our part # 11-13011.

Q: Is this good for the initial charge of a new Gill G-243 as used in Piper Archer III?

Yes, 11-10570 can be used for the initial charge on the G-243 battery.

Q: Can this Gill GC-024 charger be used as a maintainer, ie left on the battery for long periods of time?

Yes, it can be left on the battery for long periods of time.

Q: Can this Gill GC-024 charger be used on a 24 volt AGM battery?

Yes, it can.

Q: Can this be used to maintain dual 12v batteries in series installation?

Yes.

Q: What is the difference between the GC-024 and the GC-024E battery chargers?

The "E" model is made for larger batteries with an Elcon connector.

Q: Can this GC-024 be used as a trickle charger for a battery that is already installed in an aircraft?

It can be left on the battery for long periods of time, like a trickle charger. The manufacturer recommends using this with the battery removed from the aircraft so it would be at your own risk.
