Falcon Airspeed Indicator 0-80 mph With Pitot Kit

$261.95/Kit
Quantity
Add to Wishlist
Part# AS020

Overview

This package includes a ASI080M-3 airspeed indicator, as well as a pitot kit consisting of 1/4" aluminum tubing, vinyl tube, Polyethylene Hose Adapter, and Breeze Clamp.

Falcon airspeed indicators have been one of the most chosen flight instruments by kit plane builders and pilots. There are many great advantages: excellent slow speed characteristics; very progressive increments; variety of ranges; light weight; short length; affordable price; and reliability. All airspeed indicators are housed in an aluminum case and all parts are made with metal.

Model: ASI080M-3
Range: 0-80 mph
Size: 3 1/8"
Length: 3.5in/97.3mm
Weight: 10.2oz/290g

Note: Range markings not included.
If needed, order P/N 10-03905.



Made in China

California Prop 65 Warning Symbol

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

In The Box

  • Falcon ASI080M-3
  • 1 ft - 1/4" Aluminum Tubing
  • 5 ft - 1/4" ID x 3/8" OD Vinyl Tube
  • 1/4T x 1/8P Polyethylene Hose Adapter
  • Breeze Clamp
  • Accessories
  • Frequently Purchased With
  • Customers Also Viewed
  • Related Items

Reviews

Since I needed a simple pitot and tubing to go with the ASI, I figured Id order the combo. The ASI looks good. The pitot is a foot long piece of rough cut aluminum tubing with the ends unfinished and closed up. The tubing? I think the catalog says 5 feet, but I got a piece 10 inches long. Yeah, 10 inches long. Yes, I know , a trip to the hardware store and a few seconds with a file and drill bit will make things right. But the point of ordering the combo was to not have to make an extra trip.

Sam S
December 25, 2020

Q&A

Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: This is a complete kit? Gauge,hardware,? Put on ultralight,and use? Does it work like ram air in tube?

This would include the gauge and kit to make a pitot system. We believe you would need to add a static port to make it a true pitot static system. The pitot tube measures ram air pressure and the static port measures static pressure, the gauge uses both to determine airspeed.

Q: Can this be mounted from the back and/or front of instrument panel?

The instrument in this kit is designed to be mounted from the backside of the panel.
