Whelen Position Light Model 7137901 Series LED Forward Position Lights

From $329.00 to $343.00
Mfg Model# Description PN Price Buy
7137901LED Fwd POS Light (28V), Green (Replace W1250)
11-12470
$343.00
Quantity
7137902LED Fwd POS Light (28V), Red (Replace W1250)
11-12471
$329.00
Quantity
7137911LED Fwd POS Light (14V), Green (Replace W1250)
11-12472
$343.00
Quantity
7137912LED Fwd POS Light (14V), Red (Replace W1250)
11-12473
$343.00
Quantity
Subtotal $0.00
Add to Wishlist

Overview

71379 is an LED W1250 wingtip forward position light designed to be located under a fairing, but is suitable for external mounting as well. Replaces GRIMES A1815A and Whelen W1250. Product ships with 6" flying leads and is avilable in 28VDC or 14VDC.

Approvals 7137901 01-0771379-01 LED Fwd POS (Green) FAA TSO-C96a,TSO-C30c Types II 7137902 01-0771379-02 LED Fwd POS (Red) FAA TSO-C96a, TSO-C30c Types I

California Prop 65 Warning Symbol

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Specifications

  • Drawing Number: 71379
  • Voltage: 28VDC
  • Power Consumption: 0.3Amps
  • Weight: 0.5lbs (226.8gm)
  • Length: 2.31 (58.67mm)
  • Exposed Height: 1.25 (31.75mm)
  • Width: 1.75 (44.45mm)
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

Q&A

Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Does the Whelen 7137901 series LED light come with the the lense and the mount as depicted in the photo?

Yes, it does.

Q: What is 6 flying leads?

That should read 6" flying lead, it is referring to the bare wiring harness.
