- Photo may represent series and not specific product
- SHARE
Start Pac Portable 24V/28V DC Power Supply – Model 53105M™– 24/28V
$883.00/Each
Part# 11-20568
MFR Model# 53105M-24/28V
MFR Model# 53105M-24/28V
FREE Shipping
- JUMP TO
- Overview
- Features
- Specifications
- Reviews
- Q&A
Overview
|
This START PAC® model has been designed to power up 28 Volt aircraft systems and will continuously deliver up to full 105 amp DC output. The voltage output is set to 28.5 Volts to simulate the same voltage as when the aircraft is running under power. This unit requires 220 Volt single phase power to operate.
This START PAC® unit has been specifically designed for maintenance and to power up various functions such as inverters, avionics, GPS programming, etc. Using this START PAC® power supply means that the operator can bypass the aircraft battery thus preserving it from unnecessary wear. The on-board aircraft battery can be conserved for starting only. The environmentally responsible, low VOC powder coating protects the unit from wear, tear and poor weather conditions. Model: 53105M™ – 24V/28V Please Note: This unit is not designed for battery charging. Please note that on board air conditioning systems are high draw systems that usually require a minimum of 175A. |
 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
Features
- Small and light portable aircraft power supply
- No duty cycle, clean continuous power
- Voltage output 28.5 Volts and 105Amps maximum amperage output
- Resistant aluminum case with environment friendly, low VOC durable powder coat finish, easy to handle, built for heavy duty usage
- 8'/2.4m aircraft attached cable
- If overloaded, the unit will trip off and reset itself after a short period of time
Specifications
| Maximum Continuous Current output | 105 A |
|---|---|
| DC voltage output | 28.5 VDC |
| AC voltage input | 180 – 240 VAC |
| AC current input at maximum DC power output | 14 A @220VAC |
| Phase | Single |
| Forced air-cooling | Yes |
| Over current protection | Yes |
| Over voltage protection | Yes |
| Over temperature protection | Yes |
| Complete weight with aircraft cables | 12lbs / 5.4kg |
| Dimensions Length x Width x Height | 16″ x 4.375″ x 5.25″ 40 x 11.5 x 13.3 cm |
