Maule Tailwheel Parts List

MAULE TAILWHEEL PARTS LIST

Old Style (Pre 1976) has 3/4" Fork Shaft &		Old Style SFS-P8 Pneumatic or SFS Solid Rubber	New Style SFS-P8A Pneumatic and SFSA Solid Rubber	Qty. Reqd	Price Each	Buy
New Style (Post 1976) has 7/8" Fork Shaft
Fig. #	Description	Part Number	Part Number
1	Cover Cap	TW-18 (1-1/4")	TW-63A (1-3/8")	1	>	>
2	Nut	AN364-720 or	AN364-720 or	1	>	>
		AN365-720	AN365-720		>	>
3	Lock Ring Pin	TW-17	TW-60AB	1/2	>	>
4	Lock Ring	TW-16	TW-57A	1	>	>
5	Nut	AN364-440	AN364-440	3	>	>
6	Steering Arm Assembly*	TW-15	TW-15A	1	>	>
7	Bracket Assy., 1-1/4 In	06-16101	06-16201	1	>	>
	Bracket Assy., 1-1/2 In	06-16102	06-16202	1	>	>
	Bracket Assy., 1-3/4 In	TW-22-3-4		1
8	Lock Pin	TW-13	TW-13	1	>	>
9	Steering Arm Spring	TW-14	TW-14	1	>	>
10	Lock Cover Plate	TW-12	TW-12	1	>	>
11	Screw	MS35206-217	MS35206-217	3	>	>
12	Cam	TW-10	TW-10	1	>	>
13	Screw	AN501-10-4	AN501-10-4	2	>	>
	AN520-10-4	AN520-10-4
14	Zerk Fitting	TW-7-A14	TW-7-A14	1	>	>
15	Oilite Bearing	TW-7 (3/4" I.D.)	TW-59A (7/8" I.D.)	1	>	>
16	Cotter Pin	AN380-3-3	AN380-3-3	1	>	>
17	Screw	TW-A18	TW-A18	3	>	>
18	Hub Cap	TW-27	TW-27	1	>	>
19	Axle Nut	AN320-8	AN320-8	1	>	>
21	Tire­solid, no bearings	TW-23	TW-23	1	>	>
	Tire­solid, with bearings	TW-23A	TW-23A	1	>	>
22	Bearing (with washer)	TW-A15	TW-A15	1	>	>
23	Washer	TW-28	TW-28	1	>	>
24	Felt Seal	TW-26	TW-26	1	>	>
25	Retainer Washer	TW-64	TW-64	1	>	>
26	Fork (without axle)
	Pneumatic	TW-39	TW-58A	1	>	>
	Solid Rubber	TW-21	TW-61A	1	>	>
	Fork (with axle)
	Pneumatic	TW-39-1	TW-58A-1	1	>	>
	Solid Rubber	TW-21-1	TW-61A-1	1	>	>
27	Axle	TW-5	TW-5	1	>	>
28	Axle Sirclip Ring	TW-6	TW-6	1	>	>
29	Bearing	TW-A7	TW-A7	2	>	>
30	Inboard Wheelhalf, w/bearings	TW-30	TW-30	1	>	>
31	Tire, 8-inch			1
32	Tube			1
33	Outboard Wheelhalf	TW-31	TW-31	1	>	>
34	Washer	TW-A6	TW-A6	1	>	>
35	Lock Washer	AN935-516	AN935-516	3	>	>
36	Bolt	TW-A12	TW-A12	3	>	>
37	Hub Cap	TW-32	TW-32	1	>	>
38	Hub Cap Sirclip Ring	TW-33	TW-33	1	>	>
39	Cotter Pin	AN380-3-3	AN380-3-3	1	>	>
40	Adjusting Screw	TW-40		1	>	>
41	Dampener Spring	TW-41		1	>	>
42	Friction Block	TW-42		1	>	>
43	Hex Housing	TW-43		1	>	>
44	Bracket Assembly,
	Bracket Assembly,

WE BEAT ANY COMPETITORS ADVERTISED PRICES!

Description Part No. Price Buy MAULE TAILWHEEL CAP TW-63A TW-63A $5.50 NUT, ELASTIC STOP MS21083N7 AN364-720 $1.14 NUT, ELASTIC STOP AN365-720 AN365-720 $0.78 MAULE LOCK RING PIN POST 1976 TW-60AB $0.28 MAULE LOCK RING TW-57 TW-57A $15.40 ELAS STOP NUT MS21083N04 AN364-440 $0.21 MAULE TAILWHEEL STEERI TW-15A TW-15A $66.25 MAULE BRACKT ASSY TW-22A 1-1/4 06-16201 $132.95 MAULE BRACKT ASSY TW-22A 1-1/2 06-16202 $86.50 MAULE TAILWHEEL LOCK PIN TW-13 TW-13 $14.90 MAULE TAILWHEEL SPRING TW-14 TW-14 $0.19 MAULE TAILWHEEL PLATE TW-12 TW-12 $4.00 MACHINE SCREW MS35206-217 MS35206-217 $0.03 MAULE TAILWHEEL CAM TW-10 TW-10 $8.80 FILLISTER HD SCREW AN501-10-4 AN501-10-4 $0.38 MAULE ZERK FITTING TW-7-A14 $2.20 MAULE TW-59A BEARING 7/8 ID TW-59A $9.60 COTTER PIN AN380-3-3 AN380-3-3 $0.02 MAULE SCREW TW-A18 $0.12 MAULE TAILWHEEL REF. # TW-27 TW-27 $11.80 NUT, SHEAR AN320-8 AN320-8 $1.26 MAULE TIRE 6.50 X 2.50 # TW-23 TW-23 $62.75 MAULE TAIL TIRE W/ BEAR TW-23A TW-23A $96.35 MAULE BRNG W/WASHR F350-12 TW-A15 $14.75 MAULE TAILWHEEL WASHER TW-28 TW-28 $1.58 MAULE TAILWHEEL FELT TW-26 TW-26 $0.28 MAULE TAILWHEEL TW-64 WASHER TW-64 $0.12 MAULE T.W. P8A FORK TW-58A TW-58A $81.50 MAULE T-WHEEL SFSA FORK TW-61A TW-61A $77.50 MAULE FORK W/ AXLE TW-58A-1 TW-58A-1 $78.75 SFSA FORK W/AXLE # TW-61A-1 TW-61A-1 $82.00 MAULE AXLE W/ SIRCLIP TW-6 TW-5 $31.75 MAULE SIRCLIP RING TW-6 TW-6 $0.34 MAULE BEARING TW-A7 $34.50 MAULE INSIDE HB W/BEARNG TW-30 TW-30 $97.45 MAULE OUTSIDE HUB TW-31 TW-31 $31.75 MAULE WASHER TW-A6 $0.34 WASHER MS35338-45 (AN935-516) AN935-516 $0.03 MAULE BOLT TW-A12 $3.00 MAULE TAILWHEEL TW-32 HUB CAP TW-32 $14.50 MAULE T-WHEEL TW-33 SIRCLIP TW-33 $1.42 COTTER PIN AN380-3-3 AN380-3-3 $0.02 MAULE # TW-40 TW-40 $0.56 MAULE # TW-41 TW-41 $0.48 MAULE FRICTION BLOCK TW-42 TW-42 $13.20 MAULE # TW-43 TW-43 $13.60
